iXsystems AX-1112A (Gen 4)
1U Single AMD EPYC Processor Server

The iXsystems iX Series is a line of enterprise-grade rackmount servers designed to deliver reliable performance, versatility, and scalability for a wide range of workloads. The iX Series includes servers with various configurations, such as the AX-1112A, which features a 1U form factor, a single AMD EPYC 9004 processor, 24 DIMM slots with support for up to 6TB of total memory, and dual 1GbE network connectivity. The AX-1112A also provides flexible storage options, including 12 x 2.5” SATA/SAS/NVMe drive bays. Additionally, the server is equipped with two PCI-E 5.0 x16 slots, one PCI-E 5.0 x16 OCP slot, and two M.2 slots, allowing for expandability and customization based on the needs of the deployment. Overall, the iXsystems iX Series servers are built to offer robust performance and efficiency for modern data centers and IT environments.

Key Applications

• Web Server, Firewall Application
• Data Center Optimized, Value IaaS
• Cloud Computing, Compact Server
• Virtualization
• CDN, Edge Nodes
• DB Processing & Storage

Outstanding Features

• 24 DIMM Slots – Up to 6 TB total memory
• 12 x 2.5” Hot-Swap NVMe/SATA/SAS Drive Bays
• 2 x PCI-E 5.0 x16 Slots
• 1 x PCI-E 5.0 x16 OCP
• 2 x M.2 Slots
