Industry · Manufacturing

Storage for the Production Floor and the Design Office

TrueNAS unifies CAD/CAM file shares, PLM archives, production floor data, and OT network storage on a single platform — with OpenZFS integrity, SMB/NFS multi-protocol access, and no per-TB licensing fees.

Request a Quote Browse Hardware

TrueNAS manufacturing and industrial storage

The Challenge

Manufacturing IT spans two very different environments: the enterprise IT network running ERP, PLM, and engineering workstations — and the OT network running SCADA, MES, and production floor systems. Both generate data that must be stored reliably, but each has different performance, connectivity, and reliability requirements. Deploying separate storage silos for each is expensive and creates a data integration problem that complicates analytics and reporting.

TrueNAS provides a unified platform that handles both environments. SMB shares for Windows-based engineering workstations running CAD and PLM applications. NFS mounts for Linux-based simulation servers. iSCSI LUNs for production floor servers. And S3-compatible object storage for industrial IoT data pipelines that use cloud-native tooling on-premises. A single TrueNAS appliance consolidates storage that would otherwise require three separate purpose-built systems.

How TrueNAS Supports Manufacturing Operations

From CAD file shares to production floor IoT data, a unified storage platform across your entire manufacturing enterprise.

Engineering and Design Storage

CAD/CAM and PLM File Shares

TrueNAS serves SMB shares to engineering workstations running CATIA, SolidWorks, NX, and Creo simultaneously from the same storage pool. Large assembly files and simulation outputs that saturate direct-attached storage are loaded from NVMe-cached TrueNAS pools over 25/100 GbE — eliminating the “waiting for the file to open” complaint that follows any shared CAD storage deployment. Immutable ZFS snapshots protect design history: every version of a part file is recoverable without a separate PLM backup system.

Simulation and FEA Storage

Finite element analysis and CFD simulation jobs generate large result sets quickly. TrueNAS NVMe throughput and NFS access for Linux simulation servers ensures result files are written at full speed without the simulation waiting on storage.

Document and Standards Archives

ISO standards documents, engineering specifications, work instructions, and quality records are long-lived and must remain verifiably unmodified. OpenZFS checksums guarantee that a document retrieved 10 years later matches exactly what was stored — critical for ISO 9001 and IATF 16949 compliance.

Production Floor and OT Storage

MES and SCADA Data Storage

TrueNAS iSCSI block storage for MES (Manufacturing Execution System) and SCADA servers provides the low-latency access that production applications need while keeping data off direct-attached drives that fail without warning on the production floor.

Industrial IoT and Sensor Data

TrueNAS S3-compatible object storage via MinIO AIStor provides a local landing zone for IoT sensor streams, machine telemetry, and quality inspection image data — using the same S3 API as cloud platforms without routing data offsite for every write.

Vision System and QC Image Storage

Machine vision systems and automated optical inspection generate large volumes of high-resolution images for quality traceability. TrueNAS stores inspection images with sequential-write optimization, making write performance predictable under sustained ingest loads.

OT Network Isolation

TrueNAS VLAN support and per-dataset access controls allow IT and OT networks to share the same physical TrueNAS appliance while maintaining network-layer isolation between enterprise and production floor data — satisfying ICS security requirements.

Reliability and Business Continuity

OpenZFS Self-Healing

Production floor environments are hard on drives. OpenZFS detects and corrects silent data corruption caused by vibration, power fluctuations, and aged hardware — ensuring that quality records and production data are recoverable and verifiable years after they are written.

Ransomware-Resistant Snapshots

Immutable ZFS snapshots protect design files, quality records, and production data from ransomware. A manufacturing company can roll back an entire file share to a pre-attack state without paying a ransom or triggering a production stoppage.

Dual-Controller HA Options

TrueNAS F-Series and M-Series ship with dual active-standby controllers. A single controller failure does not interrupt access to production floor applications or engineering workstations — failover completes transparently to connected clients.

Site-to-Site Replication for DR

Replicate critical design files and production data to a second facility TrueNAS on a defined RPO schedule. Encrypted ZFS replication over existing WAN links eliminates the need for a separate DR appliance at the secondary site.

Recommended TrueNAS Systems for Manufacturing

Models commonly chosen for this workload, with reasoning.

R-Series

TrueNAS R20

12+2-bay hybrid · 3.4 PB

Cost-effective hybrid for plant-floor file shares and IoT data ingest — easy to operate, long warranty.

View R20 →

R-Series

TrueNAS R50

48+4-bay hybrid · 6.5 PB

Higher-density hybrid for PLM, CAD libraries, and inspection-image retention.

View R50 →

H-Series

TrueNAS H20

2U · 10-core · 4 GB/s

NVMe-accelerated hybrid for engineering teams pulling large CAD assemblies — faster metadata path than pure HDD.

View H20 →

Authorized TrueNAS Reseller

Consolidate your manufacturing storage

Tell us your engineering application stack, production floor requirements, site count, and current storage setup — we’ll configure the right TrueNAS and stay on the order until it ships.

Talk to a Specialist

Recommended Hardware for Manufacturing

Plant / Factory Storage

TrueNAS R-Series

1U–4U single-controller rackmount for production floor and edge deployments. R20 and R50 provide high-density, cost-effective storage for MES, SCADA, and quality systems in space-constrained factory environments.

View R-Series

Engineering & Corporate IT

TrueNAS H-Series

Dual-controller hybrid NAS with NVMe caching for engineering workstations and corporate file shares. Up to 8 GB/s and 3 PB raw — cost-effective for CAD/PLM environments with HA requirements.

View H-Series

Simulation & Digital Twin

TrueNAS F-Series

All-flash dual-controller HA with up to 20 GB/s for FEA, CFD, and digital twin simulation workloads that require flash-tier IOPS and dual-controller availability.

View F-Series
